Suitable for installation between Flanges of : PN10 , JIS 10K , ANSI 150
Size:2", 2 1/2 ",3",4",5",6" ,8"(worm gear),10",12"
Size:DN50,DN65,DN80,DN100,DN125,DN150,DN200 (worm gear),DN250 , DN300
Valve Specifications
Body Material:Cast Steel /Ductile Iron
Disc:Stainless Steel 316
Stem:Stainless Steel 403
Seat:EPDM
Actuator Specifications
Body Material : Extruded Alluminium Alloy, Gold Anodized
End Cap : Presssure Die Casting Alluminium Alloy with Black Epoxy Coated
Air Pressure:max. 10 bar
2 Type of Actuators
1. Double Acting
2. Spring Return
Accessories (optional) :
a. Position Feedback Limit Switch
b. Pilot Solenoid Valves
c. I/P Positioners
d. Gear Box Manual Override
e. Stroke Limiters
f. 3 Positions Pneumatic Actuators
